SWITCH DAHUA PFS3210-8ET2GF-96 10-Port Unmanaged Desktop Switch with 8-Port PoE

005338

- Reseaux > Réseautage commercial > Switch Réseau

· Hardware
· Included Power Adapter · Yes
· PoE · Yes
· Ethernet Port · 8
· Ethernet Port Speed · 10/100 Mbps
· Ethernet Port Uplink Speed · 10/100/1000 Mbps
· Optical Port Uplink Speed · 1 Gbps
· Description of Function Slots · Port 1-8: 8 × 10/100 Base-T (PoE) Uplink 1-2: 2 × 10/100/1000 Base-T (Combo) Uplink 1-2: 2 × 1000 Base-X (Combo)
· Power Supply · 53 VDC, 1.81 A
· Operating Temperature · –10 °C to +55 °C (+14 °F to +131 °F)
· Operating Humidity · 10%–90% (RH)
· Storage Temperature · –40 °C to +70 °C (–40 °F to +158 °F)
· Storage Humidity · 5%–95% (RH)
· Power Consumption · Idling: 3 W Full load: 96 W
· Performance
· Layer · Unmanaged
· Management Type · No
· Smart Managed Switch · No
· MTBF · 88.03 year
· Switching Capacity · 5.60 Gbps
· Packet Forwarding Rate · 4.17 Mpps
· Packet Buffer Size · 4 Mbit
· Jumbo Frame · 9.6K Byte
· MAC Table Size · 8K
· Communication Standard · IEEE802.3; IEEE802.3u; IEEE 802.3ab; IEEE802.3x
· PoE
· PoE Protocol · IEEE 802.3af; IEEE 802.3at; Hi-PoE; IEEE 802.3bt
· PoE Power · Port 2-8 ≤30 W, port 1 ≤90 W, total ≤96 W
· PoE Power Consumption Management · Yes
· PoE Pin Assignment · 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
· Long Distance PoE Transmission · Yes
· General
· Statics Protection · Air discharge: 8 kV Contact discharge: 6 kV
· Lighting Protection · Common mode: 4 kV Differential mode: 2 kV
· Net Weight · 0.65 kg (1.43 lb)
· Gross Weight · 1.4 kg (3.09 lb)
· Product Dimensions · 240 mm × 105 mm × 28 mm (9.45" × 4.13" × 1.10")
· Packaging Dimensions · 279 mm × 239 mm × 89 mm (10.98" × 9.41" × 3.50")
· Casing Material · Metal
· Installation · Desktop mount
· Certifications · CE; FCC
·
· Transmission Performance:
· Switch power supply voltage 53V. · CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m
· Cable(m) · Load Capacity(W) · Bandwidth(Mbps)
· IEEE802.3bt 90 W
· 100 · 71.3 · 100
· 150 · 62 · 10
· 200 · 51 · 10
· 250 · 40 · 10
· Hi-PoE 60 W
· 100 · 53 · 100
· 150 · 50 · 10
· 200 · 47 · 10
· 250 · 37 · 10
· IEEE802.3at 30 W
· 100 · 25.5 · 100
· 150 · 25.5 · 10
· 200 · 25.5 · 10
· 250 · 25.5 · 10
·
·

Informations supplémentaires

-100 Mbps PoE ports and gigabit uplink ports. -The red port meets the IEEE 802.3bt standard. -Power supply supports up to 90 W. -PoE watchdog monitors the status of terminals in real-time. -Supports 250 m long-distance power supply. -Supports the power management policy. -8-pin PoE offers better compatibility and reduces cable loss. -Durable full-metal housing provides great heat dissipation.
